USS Boggs was originally commissioned as a flush-deck four pipe destroyer in 1918. Shortly before the start of the Second World War, she was converted to a Destroyer Minesweeper, a configuration she kept until June of 1945 when her mine sweeping gear was removed and she was converted to a high-speed target towing vessel.


Booklet of General Plans

USS Boggs DMS-3 - Sheets 1, 2, and cover, 1941

Outboard Profile, Inboard Profile, Information

USS Boggs DMS-3 - Sheets 3, 4, 5, and 6, 1941

Main Deck, 1st & 2nd platforms with superstructure decks, and hold.

USS Boggs DMS-3 - Sheets 7, 8, 9, & 10 1941

Fire mains and drainage system inboard profile and Main Deck, 1st and 2nd platforms, and hold.
Sheet 10 contains general information for the ship as a DMS.

USS Boggs DMS-3 - Sheets 11, 12, and 13 1941

Transverse sections and fuel-oil repairs

Ghosts of configurations past are visible in this image - note that all four stacks were lowered before the fourth stack was eliminated. Past masts and rigging are also visible.
